aluminum TR4 TR5 TR6 steel sheet making machine colored steel wall roof panel cold roll forming machine
Application of Roof Roll Forming Machine
The TR4 TR5 TR6 Roll Forming Machine can process galvanized steel plate, which is made of products with beautiful appearance and smooth lines. It is mainly used for interior and exterior walls and floor panels of industrial and civil buildings. It has large peaks, high strength and installation points. After welding the steel mesh, it is combined with concrete on-site watering and has good adhesion. In the high-rise building, the steel formwork can be omitted and the floor load can be reduced. Under the premise of equal bearing capacity, the amount of engineering steel is reduced, and the quantitative input cost is saved.
Roof Roll Forming Machine Technical parameters
| 1 | Suitable to process | Color steel plate, galvanized sheet, aluminum coils |
| 2 | Width of the feeding material | 914-1250mm |
| 3 | Roller station | 11-18 rows or custom as customer's requirements |
| 4 | Thickness of feeding material | 0.3-0.8mm |
| 5 | Productivity | 10-15 m/min |
| 6 | Rollers' material | 45# steel |
| 7 | Diameter of shaft | 70-80mm |
| 8 | Voltage | 380V 50Hz 3Phases |
| 9 | Main forming machine body | 300-400 mm H steel |
| 10 | Motor power | 4-7.5 kw |
| 11 | Weight | About 5-15T |
| 12 | Custom | According to customer's requirements |
Main Components
| No. | Name | Qty |
| 1 | Manual uncoiler | 1 |
| 2 | Main roll forming machine | 1 |
| 3 | PLC Control box | 1 |
| 4 | Hydraulic pump station | 1 |
| 5 | Output table | 2 |
Profile drawing to design of Roof Roll Forming Machine
Machine pics
After service
Shipping pics
FAQ
1. Q: What's the warranty period? (24hours online)
12 months warranty period, starting from the date of the successful installation and commissioning of the equipment at the Buyer’s Installation site. During which all parts damaged because of quality problem will be changed for free.
2. Q: Do you have installation and commissioning service?
A.If buyers come to our factory to inspect, the training to install and operate is provided face to face. If not, manual and video is provided to show how to install and operate.
B. If buyer need we will send technician to buyer site to do installation and commissioning and training.
C.installation and commissioning cost: One engineer will visit Buyer’s workshop for installing, commission and training. The buyer has to pay USD100/per day and visa fee, air tickets fee, accommodation and food, necessary communication, etc.
(Normally ,It takes about a week to install )
3. Q: What’s your after-sales service ?
We provide 24-hour online service for our customers.
And we are happy to give advice and also have skilled technicians available to maintain the machine overseas to customers’ workshop if needed.
4. Q: What's your delivery time ?
Normally we can finish production and testing within 45-70 days after receiving deposit. Some machines in stock, can be delivered at any time
5. Q: You are trading company or factory?
We are Manufacturer, and we export our machine by ourselves.
6. Q: Do you provide customized machine?
Sure, we can design the machine according to the requirement and profile drawing you provide. Our engineers can offer the best professional solution to our worldwide clients.
7. Q: How to visit your factory?
We are in jiangyin city,belongs to Jiangsu province,
near Shanghai. If you arrive at Shanghai Airport,we can pick you up
It is 160 kilometers from Pudong Airport, about 3 hours.
It's 110 kilometers from Hongqiao airport, about 2 hours; It's 125 kilometers from downtown Shanghai about two and a half hours.
It is very convenient.Please let me know if you have booked the tickets
so that I can prepare and book a hotel for you,we will arrange for car to pick you up.
By high speed train from Shanghai to East Wuxi (Wuxi Dong station), half an hour.
Product Tags:
|
|
TR6 Aluminum Steel Sheet Making Machine , Steel Sheet Roll Forming Machine Images
|
